150kg Loading And Unloading Robot Arm Pneumatic Manipulator With Magnet For Iron Plate Handling

Equipment Introduction

It’s a manipulator designed for steel plates that will deform during handling, and the manipulator needs to move the flat iron plate to the processing equipment, and after it is bended, move it off, and stack it. It integrates two sets of fixtures, one of which is a magnet - used to adsorb the flat iron plate before pressing, and the other is a tailored gripper for clamping the deformed plate after being pressed. The two sets of fixtures work in a staggered manner, with infinite loops and perfect fit.

Design sketch

     Advantages of the device

High Customization: Non-standard customized manipulators can be tailored to specific requirements, offering personalized solutions that are designed to meet unique industry or process needs.

Enhanced Adaptability: These manipulators can adapt to a wider range of shapes, sizes, and weights of objects, providing greater flexibility in handling various types of workpieces.

Improved Productivity: Customized manipulators can be optimized to suit the characteristics of a production line, thus boosting productivity and reducing operational costs.

Space Efficiency: Non-standard customized manipulators can be designed to fit specific spatial constraints, maximizing space utilization and enhancing layout efficiency on the production floor.

Enhanced Quality Control: Tailored designs allow for better integration with production processes and requirements, leading to improved product quality and consistency.

The handling of this equipment is that the metal plate is fed and the workpiece is flat, which can be adsorbed with magnets, and the workpiece has been pressed and deformed, and the customized fixture is reclaimed, which solves the customer's handling problem very well, safe and efficient.
